Low Mag 1/2' Sensor Telecentric Lens

  • Standard resolution telecentric lens

  • Magnification range from 0.0205X to 0.218 X

  • Bi-telecentric design and object telecentric design

  • Suitable for various applications, alignment, inspection, measurement, etc.

  • C mount

Get Started
Low Mag 1/2' Sensor Telecentric Lens
  • Specification Of Low Mag 1/2' Sensor Telecentric Lens
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)
Model Optical Size Sensor Length (mm) Sensor Width (mm) Diagonal (mm) FOV Length (mm) FOV Width (mm) Lens Length (mm) Max Diameter (mm) Preview (pdf)

XF-PTL39008-C

1/2'

6.4

4.8

8

312.2

234.1

1032.7

430

XF-PTL35008-C

1/2'

6.4

4.8

8

279.5

209.6

812.4

376

XF-PTL31008-C

1/2'

6.4

4.8

8

248.1

186

740.1

340

XF-PTL26808-C

1/2'

6.4

4.8

8

214

160.5

673.8

300

XF-PTL23808-C

1/2'

6.4

4.8

8

190.5

142.9

615.2

270

XF-PTL19508-C

1/2'

6.4

4.8

8

155.7

116.8

467.2

222

XF-PTL18208-C

1/2'

6.4

4.8

8

145.5

109.1

440.7

210

XF-PTL15208-C

1/2'

6.4

4.8

8

121.2

90.9

392.8

180

XF-PTL13708-C

1/2'

6.4

4.8

8

109.4

82.1

353.7

166

XF-PTL12208-C

1/2'

6.4

4.8

8

97.6

73.2

345.7

166

XF-PTL11008-C

1/2'

6.4

4.8

8

88

66

307.1

130

XF-PTL09208-C

1/2'

6.4

4.8

8

73.2

54.9

257.8

120

XF-PTL08008-C

1/2'

6.4

4.8

8

64

48

233.1

104

XF-PTL06508-C

1/2'

6.4

4.8

8

52

39

198.5

90

XF-PTL05508-C

1/2'

6.4

4.8

8

43.8

32.9

182.8

79

XF-PTL04508-C

1/2'

6.4

4.8

8

36

27

139.8

70

XF-PTL03708-C

1/2'

6.4

4.8

8

29.4

22

107.7

70
